Monthly Archives: October 2012

Dong Shin 10.31.2012

wrapping up SQLEditor for VSS
- added getSavedSQLs to retrieve save queries
- added SQL error window to FGMFlexUtils45
- double click on sqlResultsDG shows selected row details
fgmdev.com was down….

Phil 10.31.12

8:00 – 4:00

Backups and discussions with folks on site. Working on getting a meeting set up with the Morpheus folks.
fgmdev.com was down. Dong and I spent most of the morning trying to get it up. That you are reading this means success!
Working on adding color code. Incorporated and working nicely!
Checking code in
Burning a disk

Phil 10.30.12

10:00 – 12:00 ESSO

Still wet, but no wind to speak of. Cold – in the 30’s. We apparently got 80 mph gusts and I’d believe it.
Updated the WP engine for this blog.
Looking at some papers about User Interface/ Experience to see how the Alert Manager App should be built.

12:00 – 2:00 FP

Reading “Facilitators and Barriers to Adopting Robotic-Assisted Surgery: Contextualizing the Unified Theory of Acceptance and Use of Technology”. I want to find a rule for User Interface adoption
“

Dong Shi 10.29.2012

working at home
continue working on SQLEditor for VSS
- added method to run SQL string to server – SQLResult runSQLStrings(String databaseName, String sqlList)
- added SQLResult.java to javaUtils – pom.xml is set to generate version 1.1, others are not using it?????
  - changed scriptingEngine and VisibilityScriptingServer to use 1.1
- added methods to save and get list of SQLs

Phil 10.29.12

8:00 – 4:00 ESSO

So begins a very wet day.
Working on figuring out why coloring chart lines is so different from all the other charts. Going to try building a toy project with just one line chart in it and (maybe?) an item renderer.
Well that turned out to be easier than I thought.

	private function init():void{
		var hsb:HsbObject = new HsbObject(0x0000AA);
		var lsa:Array = new Array();
		lsa.push(createLineSeries("Profit", "Profit", hsb));
		hsb.rotateHue(40);
		lsa.push(createLineSeries("Expenses", "Expenses", hsb));
		hsb.rotateHue(40);
		lsa.push(createLineSeries("Amount", "Amount", hsb));

		_linechart.series = lsa;
	}

	private function createLineSeries(yf:String, dn:String, hsb:HsbObject):LineSeries{
		var scs:SolidColorStroke = new SolidColorStroke(hsb.getHexColor());
		scs.weight = 3;
		var ls:LineSeries = new LineSeries();
		ls.yField = yf;
		ls.displayName = dn;
		ls.setStyle("lineStroke", scs);
		return ls;
	}

The project files are here. There are two projects. The EdgeUtils project contains the HsbObject class.

Dong Shin 10.26.2012

added dbStoredQuery(String queryName) to ScriptFacades class
- can run set of queries and return the last result in DbTable format
working on dbStoredProc – runs stored procedure in the database via VSS
working on QueryEditor in VSS

Phil 10.26.12

8:00 – 4:00 ESSO

Put in the paperwork for an URN
Pinged the Morpheus folks to see how we can integrate
Working on tracking down bugs and coloring lines
Discussed how to add SQL stored(?) procedures to VSS with Dong.
- Need an editor to create and name scripts
- Need some kind of macro substitution
- Some of this is available in the dbObjects in JavaUtils and FGMUtils, using the classes that I wrote to create databases that map to Flex objects.
Fixed the bug that was crashing the column rendering in WidgetBase by adding a try/catch block and resetting the array of visibile columns. Not pretty, but it works.
Still trying to figure out how to change the color of a line. This seems to be the way: http://help.adobe.com/en_US/flex/using/WS2db454920e96a9e51e63e3d11c0bf69084-7c52.html

Phil 10.25.12

8:00 – 2:00 ESSO

Got the following error:
RangeError: Index ‘2’ specified is out of bounds.

[C:autobuild3.xframeworksprojectsframeworksrcmxcollectionsListCollectionView.as:529]
at mx.collections::ListCollectionView/addAll()[C:autobuild3.xframeworksprojectsframeworksrcmxcollectionsListCollectionView.as:512]
at com.edgeti::WidgetBase/listColumnsHandler()[C:PhilProject WorkspacesHelios_3.6 FB4.5_32_bit_Aug_2012GenericQueryWidgetsrcmainflexcomedgetiWidgetBase.as:236]
Backups
Status meeting
- Dave wants a contingincy plan if the server goes down. Need to talk to Vernon about this.
- Looked at integrating with Morphious.

Dong Shin 10.25.2012

status meeting
working on running stored queries in ScriptFacades class
continue working on FMP alerts
created AlertFMPs.py and AlertFMPsSaveToTable.py scripts
query to find offending FMP’s in Alert format
- SELECT
  GROUP_CONCAT(distinct(ppa.login)) as porfolio_admins,
  GROUP_CONCAT(distinct(ppm.login)) as portfolio_mgrs,
  GROUP_CONCAT(distinct(psf.login)) as service_finance_pocs,
  GROUP_CONCAT(distinct(m.login)) as service_project_managers,
  p.project_number as program,
  c.center_number as MIPR
  FROM `financial_mitigation_plans` fmp1, financial_mitigation_plans fmp2,
  projects p, obligations_outlays o, budget_centers c,
  _projects_service_project_mgrs m,
  _projects_portfolio_admins ppa,
  _projects_portfolio_mgrs ppm,
  _projects_service_finance_pocs psf
  WHERE fmp1.obligation_outlay_uid = fmp2.obligation_outlay_uid
  AND fmp1.financial_mitigation_plan = fmp2.financial_mitigation_plan
  AND fmp1.explanation1 = fmp2.explanation1
  AND fmp1.explanation2 = fmp2.explanation2
  AND fmp1.explanation3 = fmp2.explanation3
  AND fmp1.explanation4 = fmp2.explanation4
  AND fmp1.explanation5 = fmp2.explanation5
  AND fmp1.month + 1 = fmp2.month
  AND p.uid = o.project_id
  AND c.uid = o.funding_id
  AND p.uid = m.project_id
  AND p.uid = ppa.project_id
  AND p.uid = ppm.project_id
  AND p.uid = psf.project_id
  AND fmp1.obligation_outlay_uid IN
  (SELECT o.uid
  FROM projects p, budget_centers c, budget_amounts a, obligations_outlays o, obligations_outlays_goals g
  WHERE
  p.uid = c.project_id
  AND a.budget_center_id = c.uid
  AND o.project_id = p.uid
  AND o.funding_id = c.uid
  AND g.appropriation = c.appropriation
  AND g.year = o.year_count
  AND o.year + o.year_count = 2014
  AND (ISNULL(o.month_1) OR (o.month_1 > TRUNCATE(a.amount * IF(o.type LIKE ‘%Obligate%’,g.obligation_month_1, g.outlay_month_1) / 100, 2) * 1.05
  AND o.month_1 < TRUNCATE(a.amount * IF(o.type LIKE ‘%Obligate%’,g.obligation_month_1, g.outlay_month_1) / 100, 2) * 0.95)))
  GROUP BY o.uid

Dong Shin 10.24.2012

query to find offending (?) FMPs for underperforming obligations/outlays
- SELECT *
  FROM `financial_mitigation_plans` fmp1, financial_mitigation_plans fmp2
  WHERE fmp1.obligation_outlay_uid = fmp2.obligation_outlay_uid
  AND fmp1.financial_mitigation_plan = fmp2.financial_mitigation_plan
  AND fmp1.explanation1 = fmp2.explanation1
  AND fmp1.explanation2 = fmp2.explanation2
  AND fmp1.explanation3 = fmp2.explanation3
  AND fmp1.explanation4 = fmp2.explanation4
  AND fmp1.explanation5 = fmp2.explanation5
  AND fmp1.month + 1 = fmp2.month
  AND fmp1.obligation_outlay_uid IN
  (SELECT o.uid
  FROM projects p, budget_centers c, budget_amounts a, obligations_outlays o, obligations_outlays_goals g
  WHERE
  p.uid = c.project_id
  AND a.budget_center_id = c.uid
  AND o.project_id = p.uid
  AND o.funding_id = c.uid
  AND g.appropriation = c.appropriation
  AND g.year = o.year_count
  AND o.year + o.year_count = 2014
  AND (ISNULL(o.month_1) OR (o.month_1 > TRUNCATE(a.amount * IF(o.type LIKE ‘%Obligate%’,g.obligation_month_1, g.outlay_month_1) / 100, 2) * 1.05
  AND o.month_1 < TRUNCATE(a.amount * IF(o.type LIKE ‘%Obligate%’,g.obligation_month_1, g.outlay_month_1) / 100, 2) * 0.95)))

Phil 10.24.12

8:00 – 4:00 ESSO

Working on getting auto colors to work properly in trend widget.
10:00 Meeting to talk to GAO folks. I think that went well. There will be a followup meeting.
Continued to beat on getting autopallete working for TrendWidget. After stepping through the ThresholdColumnRederer and figuring that out, I wound up with the same wrong coloring that I was getting when I ran the fill function from within the TrendWidget. The problem was that the ChartItem index was referring to each *cluster* of columns, not the columns within the cluster. As a hack to get around this, I put an Array in TrendWidget that counts the yFields that are passed to the field function. The *index* of the yFields is then used as the hue angle. Anyway, here’s the code:

protected function setColumnSeriesColor(element:ChartItem, index:Number):IFill {
	var yFieldName:String = "_unset_";
	var o:Object = element.element;

	// check if the yFieldName is in an array. if it is, then get the index. if not, add and get the index.
	if(o.hasOwnProperty("yField")){
		yFieldName = o.yField;
		if(_yfieldNameArray.lastIndexOf(yFieldName) == -1){
			_yfieldNameArray.push(yFieldName);
		}
		index = _yfieldNameArray.lastIndexOf(yFieldName);
	}
	return ColorUtil.setSeriesColor(element, index);
}

Next is getting the line charts to work with the color scheme.
Oh yeah, and add dataTip formatting to pie charts in QueryWidgetBase.

Phil 10.23.12

8:00 – 2:00 ESSO

Backups and housecleaning
Installed new vis2.swf. Not happy yet with the colors, but the commas work.
Talked to Lenny about FACTS
Got some heads up on tomorrow’s meeting.
Working with colors. I’m going to increment a fixed amount off of the border color – see how that works. Well – I think:
Well, that seems to work nicely:

Dong Shin 10.23.2012

created a script to save Planned Value alerts to Alerts table – AlertPlannedValuesSaveToTable.py
working on script to generate alerts for unchanged Financial Mitigation Plans
query to get unchanged FMPs from previous months
- SELECT *
  FROM `financial_mitigation_plans` fmp1, financial_mitigation_plans fmp2
  WHERE fmp1.obligation_outlay_uid = fmp2.obligation_outlay_uid
  AND fmp1.financial_mitigation_plan = fmp2.financial_mitigation_plan
  AND fmp1.explanation1 = fmp2.explanation1
  AND fmp1.explanation2 = fmp2.explanation2
  AND fmp1.explanation3 = fmp2.explanation3
  AND fmp1.explanation4 = fmp2.explanation4
  AND fmp1.explanation5 = fmp2.explanation5
  AND fmp1.month + 1 = fmp2.month

Phil 10.22.12

8:00 – 9:45 ESSO

Backups
Updated the index.html page to mention that we are production!
Made a printout of the xml that describes the FlexiChart that we’re using, and I think I figured out what the issue with the tooltips is. The yField does not exist as a row in the table. I need to get what the label and the mapping is for each row (series?) from the flexiChart.

9:45 – 12:15 FP

How users make applications fit their needs. Or, how users misuse Excel, Outlook, and PowerPoint.

12:15 – 4:00 – ESSO

Digging into FlexiChart to see if I can get the series information and use it in the dataTip function. Done and working.

Dong Shin 10.22.2012

working on queries to calculate actual performance of Financial data
created a script to generate alerts for planned values that are out of acceptable range (+/- 5%) – AlertPlannedValues.py
query to find planned values under or over 5%
- SELECT p.uid, c.uid, c.center_number, c.appropriation,
  a.year, a.amount,
  o.uid, o.type, o.year, o.year_count, o.month_1,
  g.uid,
  @goal_month_1 := IF(o.type LIKE ‘%Obligate%’,g.obligation_month_1, g.outlay_month_1) as goal_month_1,
  TRUNCATE(a.amount * @goal_month_1 / 100, 2) as goal_month_1_amount,
  @goal_month_1_min := TRUNCATE(a.amount * @goal_month_1 / 100, 2) * 0.95 as goal_month_1_min,
  @goal_month_1_max := TRUNCATE(a.amount * @goal_month_1 / 100, 2) * 1.05 as goal_month_1_max
  FROM projects p, budget_centers c, budget_amounts a, obligations_outlays o, obligations_outlays_goals g
  WHERE p.uid = 176
  AND p.uid = c.project_id
  AND a.budget_center_id = c.uid
  AND o.project_id = p.uid
  AND o.funding_id = c.uid
  AND g.appropriation = c.appropriation
  AND g.year = o.year_count
  AND (ISNULL(o.month_1) OR (o.month_1 > TRUNCATE(a.amount * IF(o.type LIKE ‘%Obligate%’,g.obligation_month_1, g.outlay_month_1) / 100, 2) * 1.05
  AND o.month_1 < TRUNCATE(a.amount * IF(o.type LIKE ‘%Obligate%’,g.obligation_month_1, g.outlay_month_1) / 100, 2) * 0.95))
  AND o.type = ‘Planned Obligated $:’
query to calculate goals and actuals
- SELECT p.uid, c.uid, c.center_number, c.appropriation,
  a.year, a.amount,
  o.uid, o.type, o.year, o.year_count, o.month_1,
  g.uid,
  @goal_month_1 := IF(o.type LIKE ‘%Obligate%’,g.obligation_month_1, g.outlay_month_1) as goal_month_1,
  TRUNCATE(a.amount * @goal_month_1 / 100, 2) as goal_month_1_amount
  FROM projects p, budget_centers c, budget_amounts a, obligations_outlays o, obligations_outlays_goals g
  WHERE p.uid = 176
  AND p.uid = c.project_id
  AND a.budget_center_id = c.uid
  AND o.project_id = p.uid
  AND o.funding_id = c.uid
  AND g.appropriation = c.appropriation
  AND g.year = o.year_count
